Commercial Glass Leak Detection: Causes, Signs & Solutions

Introduction

Water damage is one of the most expensive problems a commercial property can face. According to the Insurance Information Institute, water damage is one of the most common property insurance claims, affecting millions of buildings annually.

But here's what many property managers don't realize: a significant portion of that water damage originates from one source—failed or improperly sealed glass and glazing systems.

A leaking storefront, curtain wall, or window assembly doesn't just cost money in immediate repair—it cascades into bigger problems. Water infiltration leads to:

• Structural damage to surrounding materials (framing, insulation, drywall)
• Mold growth (expensive remediation, health hazards)
• Tenant complaints and lease breaks
• Building code violations
• Long-term deterioration of the façade

The frustrating part? Many glass leaks are invisible until the damage is significant. By then, you're looking at emergency repairs instead of preventative maintenance.

In this guide, I'll explain how to identify glass leaks before they become disasters, what causes them, and what your repair and prevention options are.

‍

What Is a Glass Leak and Why It Matters

A glass leak occurs when water infiltrates through or around a glazing assembly—the glass, frame, sealant, and surrounding components. It's different from a leak through the roof or walls because it's specific to the window or glass system itself.

‍

Where Glass Leaks Occur

Glass leaks can happen at several points in a glazing assembly:

1. Through the sealant joints (most common)

• Exterior sealant (caulk) that seals the glass to the frame deteriorates
• Interior sealant fails, allowing water to enter the building interior
• Sealant shrinks or cracks over time, creating pathways for water

2. Through failed seals in insulated glass units (IGUs)

• We discussed failed IGUs in detail in our previous guide on identifying failed glass units
• When an IGU seal fails, water can infiltrate not just between the panes, but potentially into the building structure

3. Through frame penetrations and connections

• Where the frame connects to the building structure
• Around fasteners and mechanical penetrations
• Along expansion joints

4. Through degraded gaskets or weatherstripping

• Rubber gaskets dry rot and lose sealing ability
• Weatherstripping around operable windows deteriorates
• This allows both water and air infiltration

5. Through the frame material itself

• Aluminum frames that aren't properly anodized or painted can corrode, creating gaps
• Wood frames can rot and develop cracks
• Improper frame installation leaves gaps

‍

Why Glass Leaks Are Dangerous

Unlike some building problems that develop slowly, glass leaks can cause rapid damage because:

Water follows gravity. Once water enters at the top of a glazing system, it flows downward, potentially affecting multiple floors before it's discovered.

Hidden damage. Water can travel behind walls and inside structural cavities, causing damage that's invisible until it's catastrophic.

Accelerated decay. Water in enclosed spaces creates the perfect environment for mold, wood rot, and insulation degradation.

Structural risk. If water reaches structural components (steel, concrete, wood), it can compromise the building's integrity over time.

Tenant liability. Water leaks into occupied spaces lead to tenant complaints, potential lease breaks, and liability claims if the water causes damage to tenant property.

This is why early detection is critical. A small leak caught and fixed today costs $500-$2,000. The same leak left unaddressed for 6 months can cost $10,000-$50,000+ in structural repair and remediation.

‍

Common Causes of Commercial Glass Leaks

Understanding what causes glass leaks helps you prevent them and identify the most at-risk areas of your building.

‍

Cause #1: Aged or Degraded Sealant (Most Common)

Sealant (caulk) is the barrier between the glass and frame, and between the frame and building structure. It's not permanent.

According to the Sealant, Waterproofing & Restoration Institute (SWRI), most exterior sealants have a lifespan of 7-15 years, depending on:

• Climate (UV exposure, temperature swings)
• Material quality (polyurethane vs. silicone vs. acrylic)
• Installation quality
• Maintenance

What happens: Over time, sealant:

• Hardens and becomes brittle
• Shrinks, creating gaps
• Loses adhesion to the substrate
• Develops cracks or spalling

When to suspect:

• Buildings 10+ years old
• Areas with significant sun exposure (UV degrades sealant faster)
• Sealant that's visibly cracked, peeling, or discolored

Prevention: Reseal windows and glazing systems every 7-10 years as part of routine maintenance.

‍

Cause #2: Improper Installation

If a glazing system is installed incorrectly from day one, it may appear fine for years before leaking becomes apparent.

What happens:

• Insufficient sealant depth or width
• Sealant applied over dirty surfaces (doesn't adhere properly)
• Gaps left between frame and building structure
• Improper flashing installation
• Gaskets installed incorrectly or omitted entirely

Why it matters: Improper installation is often not discovered until water infiltration occurs. By then, you're in reactive mode (emergency repair) instead of preventative mode.

Prevention: Always hire certified, experienced glazing contractors. The FGIA publishes installation standards that should be followed.

‍

Cause #3: Movement and Thermal Stress

Buildings move. Foundations settle, structures sway in wind, and materials expand and contract with temperature changes.

What happens:

• Movement creates stress on sealant joints
• Sealant that doesn't have adequate flexibility cracks under stress
• Cracks in sealant allow water infiltration
• In Colorado, temperature swings (winter -10°F to summer 90°F+) are particularly stressful on sealant

When to suspect:

• Corner joints or joints near structural connections (highest stress points)
• Buildings that have settled or moved
• Leaks that appear in specific locations repeatedly

Prevention: Use flexible sealants (polyurethane or silicone) that can accommodate movement. Ensure proper joint design and sealant width/depth.

‍

Cause #4: Failed Flashing or Water Management

Flashing is the metal or material component that directs water away from critical areas (like where the frame meets the building exterior).

What happens:

• Flashing becomes corroded or damaged
• Improper flashing installation leaves gaps
• Flashing separates from the frame or building
• Water bypasses the flashing and infiltrates

When to suspect:

• Leaks occur at specific locations (like above a certain floor)
• Water appears on interior walls below windows
• Visible corrosion or gaps in metal flashing

Prevention: Inspect flashing annually, especially after storms. Replace corroded or damaged flashing immediately.

‍

Cause #5: Blocked Drainage or Weep Holes

Modern curtain walls and window systems include weep holes and drainage cavities designed to collect water that gets past the first line of defense and direct it safely out of the building.

What happens:

• Weep holes become blocked by paint, caulk, or debris
• Water that should drain out accumulates inside the frame cavity
• Water finds its way into the building interior
• Mold grows in the trapped moisture

When to suspect:

• Leaks that appear after painting or maintenance
• Water stains that appear in unexpected locations (inside the frame cavity)
• Visible blockages in weep holes

Prevention: Keep weep holes and drainage systems clear. During painting or renovation, ensure weep holes aren't sealed over.

‍

How to Detect Glass Leaks: Signs and Diagnostic Methods

Glass leaks don't always announce themselves obviously. Here are the signs to watch for:

‍

Sign #1: Visible Water Stains on Interior Walls or Ceilings

This is the most obvious sign. If you see water stains near windows, around frames, or on adjacent interior walls, water is entering through the glazing system.

What it means: Water has already infiltrated. The source could be the glass, frame, sealant, or flashing.

Action required: Investigate immediately. Even if the stain is not currently wet, the pathway exists for future infiltration.

‍

Sign #2: Efflorescence or White Mineral Deposits

If you see white, chalky deposits on the glass, frame, or surrounding surfaces, it's a sign that water is (or was) present.

What it means: Water carries dissolved minerals. When water evaporates on surfaces, it leaves mineral deposits behind. This is called efflorescence.

Action required: This indicates water movement, even if it's not currently visible. Investigate the source.

‍

Sign #3: Mold or Mildew Growth Around Windows

If you see black, green, or white mold growth around window frames or on adjacent surfaces, it's a sign of chronic moisture.

What it means: Water is entering, but instead of staining, it's creating a damp environment where mold grows.

Action required: Immediate action needed. Mold is a health hazard and indicates active moisture infiltration.

‍

Sign #4: Visible Sealant Deterioration

If the sealant around your windows or glazing systems is visibly cracked, peeling, or missing, water will inevitably follow.

What it means: The primary barrier against water is compromised.

Action required: Reseal the affected areas before water infiltration occurs (preventative maintenance).

‍

Sign #5: Interior Condensation or Frost

If you see condensation on the inside of the glass or frame, it indicates moisture is present.

What it means: This could indicate an IGU failure (we discussed this in detail in our failed IGU guide), or it could indicate water infiltration from external sources.

Action required: Determine if the condensation is internal (between panes—IGU failure) or external (water infiltration). If it's external, investigate the water source.

‍

Sign #6: Musty Odors Near Windows

If you notice a musty or moldy smell near windows, even without visible mold, moisture is likely present.

What it means: Mold or other moisture-loving organisms are growing in hidden cavities or behind materials where you can't see them.

Action required: Urgent investigation needed. Hidden mold is a serious health and building issue.

‍

Sign #7: Peeling Paint or Wallpaper Near Windows

If interior finishes (paint, wallpaper, drywall) are peeling, bubbling, or deteriorating near windows, water is infiltrating.

What it means: Water is damaging interior finish materials. This suggests the water has been present long enough to cause material degradation.

Action required: Investigate immediately. The longer water is present, the more likely structural damage has occurred.

‍

Diagnostic Methods: Finding the Source of a Leak

Once you suspect a glass leak, here's how to diagnose the source:

‍

Method 1: Visual Inspection (DIY, Free)

What to do:

1. Inspect the exterior sealant around the window or frame (cracked, peeling, missing?)
2. Look for gaps between the frame and building exterior
3. Check for visible water stains or mineral deposits on the exterior
4. Inspect flashing for corrosion or separation
5. Check weep holes (are they clear or blocked?)

Accuracy: Low-Medium (identifies obvious problems, but may miss subtle issues)

Cost: Free

Timeline: 30 minutes to 1 hour per window/area

‍

Method 2: Water Testing (Semi-DIY, Low Cost)

This is a simple test you can perform if you suspect a specific window or area.

What to do:

1. Have one person spray water on the exterior of the suspected window with a hose
2. Have another person monitor the interior for leaks
3. Start at the bottom and work your way up
4. Spray gradually—don't flood the area (this simulates heavy rain)
5. Look for water appearing on interior surfaces or dripping into frame cavities

Accuracy: Medium-High (if you see water appear, you've found the leak pathway)

Cost: Free (if you have a hose) or minimal

Timeline: 15-30 minutes per area

Important note: Water testing requires care. Don't spray so hard you force water through intact sealant—you want to simulate actual rain conditions.

‍

Method 3: Thermal Imaging (Professional, Medium Cost)

A thermal imaging camera can detect moisture even when it's not visible to the naked eye. Wet materials have different thermal properties than dry ones.

What it does: Professional uses a thermal camera to identify areas of moisture infiltration, even within wall cavities.

Accuracy: High (detects moisture in hidden areas)

Cost: $500-$1,500 for professional thermal imaging survey

Timeline: 2-4 hours for a building

When to use: If visual inspection and water testing don't identify the source, or if you suspect moisture in hidden cavities.

‍

Method 4: Smoke Testing (Professional, Medium Cost)

A professional uses non-toxic smoke to trace air and water pathways. Smoke will follow the same routes as water.

What it does: Technician releases smoke near the suspected problem area and observes where it flows. This traces air/water pathways.

Accuracy: High (clearly shows water pathways)

Cost: $800-$2,000 depending on the building size

Timeline: 4-8 hours for comprehensive testing

When to use: If you need definitive proof of where water is entering before making expensive repairs.

‍

Method 5: Professional Glazing Assessment (Comprehensive, High Value)

A certified glazing contractor performs a comprehensive assessment, including visual inspection, water testing, and professional analysis.

What it includes:

• Detailed visual inspection of glazing systems
• Water testing to identify leak sources
• Assessment of sealant condition
• Flashing and installation evaluation
• Written report with recommendations and cost estimates
• Photos documenting findings

Accuracy: Very high (professional expertise identifies root causes)

Cost: $2,000-$5,000 depending on building size and complexity

Timeline: 1-2 days for comprehensive audit

When to use: If you have significant water damage or suspect widespread issues. The cost of the assessment is quickly offset by avoiding expensive emergency repairs.

‍

Repair Options: What Are Your Choices?

Once you've identified a glass leak, you have several repair options:

Option 1: Reseal the Joint (Most Common, Least Expensive)

If the problem is degraded exterior sealant, you can remove the old sealant and apply new sealant without replacing the glass or frame.

What it involves:

1. Remove old, failed sealant (high-pressure cleaning or manual removal)
2. Prepare surface (cleaning, priming if needed)
3. Apply new sealant (polyurethane or silicone, typically)
4. Allow to cure per manufacturer specifications

Cost: $200-$500 per window/frame assemblyTimeline: 1-3 days depending on quantity and weatherBest for: Isolated sealant failure, newer buildings, good framesLimitations: If the frame is also damaged or if the failure is due to frame movement, resealing alone may not permanently fix the problem

‍

Option 2: Replace the IGU (Insulated Glass Unit)

If the leak is due to failed seals in an insulated glass unit, you can replace just the glass, keeping the frame.

What it involves:

1. Remove the failed IGU
2. Clean the frame
3. Install new IGU with proper sealants
4. Reseal the joints around the new glass

Cost: $300-$800 per unitTimeline: 1-3 daysBest for: Failed IGU seals (water between panes), newer building with good framesRelated: See our complete guide to failed IGUs for more information

‍

Option 3: Replace the Entire Window or Glazing Assembly

If the frame is damaged, corroded, or if repeated resealing hasn't solved the problem, you may need to replace the entire assembly.

What it involves:

1. Remove the existing window/frame assembly
2. Prepare the opening (ensure frame is square and clean)
3. Install new window/frame system with proper flashing
4. Reseal all joints and connections
5. Install new weatherstripping and gaskets

Cost: $500-$2,000 per windowTimeline: 3-5 days per windowBest for: Widespread failure, corroded frames, repeated leaks despite repair attemptsUpside: New system has 20+ year lifespan, better performance, potential energy efficiency improvements

‍

Option 4: Install Additional Waterproofing Membranes

For problem areas or complex assemblies, a professional may recommend adding additional waterproofing layers inside the frame cavity to protect the building even if the exterior fails.

What it involves:

1. Accessing the interior frame cavity
2. Installing waterproofing membrane or pan
3. Creating proper drainage and weep hole management
4. This creates a "belt and suspenders" approach—if water gets past the primary barrier, it's still managed

Cost: $300-$800 per assemblyTimeline: 1-2 daysBest for: High-risk areas, buildings with history of leaks, critical spacesNote: This is protection against future failures, not a fix for current ones

‍

Prevention: How to Avoid Glass Leaks

The best glass leak is the one you prevent.

Preventative Maintenance Program

Establish a routine maintenance schedule:

Annual (Spring):

• Visual inspection of all exterior sealant (look for cracks, peeling, missing sealant)
• Check weep holes and drainage systems (ensure they're not blocked)
• Inspect flashing for corrosion or separation
• After winter freeze-thaw cycles, look for new cracks in sealant

Every 3 Years:

• Professional water testing of problem areas
• Detailed inspection of sealant condition
• Assessment of thermal performance (any drafts or condensation?)

Every 5-7 Years:

• Professional assessment of sealant condition
• Plan for reseal/replacement of aged sealant
• Budget for maintenance repairs before they become emergency repairs

Every 10+ Years:

• Comprehensive glazing system assessment
• Evaluate if windows/frames are approaching end of life
• Plan for replacement or major renovation

Sealant Maintenance and Replacement Program

Instead of waiting for leaks to appear, replace sealant proactively.

Recommended approach:

• Track the age of your sealant (when were windows last resealed?)
• Plan for reseal every 7-10 years
• Budget annually for maintenance (spread costs across years instead of emergency repair)
• Use high-quality sealant (polyurethane or silicone, not acrylic)
• Hire experienced applicators (proper application is critical)

Budget estimate: A 50,000 sq ft building with moderate fenestration should budget $5,000-$15,000 annually for preventative sealant maintenance.

‍

Connecting to Broader Glazing Issues

Glass leaks don't occur in isolation. They're often connected to broader building and glazing issues:

Failed IGUs and leaks often occur together. Water infiltration can lead to IGU failure, and vice versa. See our guide to identifying failed IGUs for integrated solutions.

Design-assist prevents leaks. During new construction or major renovation, proper design-assist collaboration ensures that glazing systems are designed with water management as a priority.

Energy efficiency and water management go hand-in-hand. Modern, high-performance glazing systems are designed to manage water and air infiltration while providing thermal efficiency.

‍

What Element 13 Facades Recommends

We've diagnosed and fixed thousands of glass leaks across Denver and the Colorado Front Range. Here's what we've learned:

Prevention is cheaper than repair. A $500 reseal done proactively beats a $20,000 structural repair done after damage occurs.

Professional diagnosis saves money. The cost of a professional assessment ($2,000-$5,000) is quickly offset by:

• Avoiding expensive emergency repairs
• Identifying root causes (not just symptoms)
• Getting the right fix the first time

Annual maintenance prevents emergencies. A simple annual inspection + water testing catches problems before they become disasters.

Early action matters. The longer a glass leak goes unfixed, the more damage it causes. Water damage compounds quickly.

If you've spotted signs of a glass leak or want to establish a preventative maintenance program, we can help. Element 13 Facades provides:

• Professional leak diagnosis — We identify sources using visual inspection, water testing, and thermal imaging
• Repair options assessment — We recommend the best solution (reseal, IGU replacement, or full window replacement)
• Preventative maintenance plans — We help you budget and schedule regular maintenance
• Emergency response — If you have active water infiltration, we respond quickly to prevent further damage

Serving Denver, Boulder, Colorado Springs, Fort Collins, and the entire Colorado Front Range.
